柔軟なチューブヒーター
製品説明:
The HOT CORE brand tubular heating elements are suitable for almost any heating appliance. They are easy to form while offering the highest mechanical stability and electrical properties.
Although tubular heating elements are technically quite mature and versatile, there are a variety of new and innovative solutions for many applications.
Screw-in tube heating elements are standardized and can be used for liquids such as water.
Tubular heating elements are easy to install, control and maintain, and unique designs can be tailored to your requirements. For aggressive environments, titanium or tubular heating elements with additional teflon bushings can be used.
特徴:
Withstand voltage test 1500V/S min under cold condition
Minimum insulation resistance 20MΩ
Maximum leakage current 0.75ma
Power tolerance +5%,-10%
Voltage 110V-440V
Diameters range from 1 mm to 40 mm
Heating resistance wire 0Cr25Al5, Cr20Ni80 or according to customer requirements
Air tube heater wattage ≥2w-4w/cm2
Water tube heater wattage ≥6w-10w/cm2
Die and finned tube heaters ≥8W-12w/cm2
応用
Tubular heater application:
Liquid Immersion
Plastic Molds
Dies
Labeling
Medical Equipment
Platens
Packaging Equipment
Hot Stamping
Sealing
Injection Molding
HOT CORE has been focused on the production of rosh approval flexible tubular heater since 1985, which is well-known as one of the leading manufacturers and suppliers of rosh approval flexible tubular heater. 過去数年間, 私たちは高品質で強い評判を所有していました, 信頼できるパフォーマンスと製品の強力な耐久性. あなたが興味を持っているべきです, please feel free to contact our factory.Hot Tags: rosh approval flexible tubular heater manufacturers, サプライヤー, 工場
